5g-5kg Semi-Automatic Powder Packing Machine

VIDEO

Introduction

DCS-Y5 series automatic screw powder packing machine adopts PLC and auger filling mechanism. Full stainless steel design, accord with sanitation standard to pack kinds of power into quota package.

Application:

The powder packaging machine is mainly suitable for powder, fine powder quantitative packaging materials, such as: flour, milk powder, pesticides, veterinary drugs, dyes, chemicals, food ingredients, additives, enzyme preparation etc.

Features:

• The principle of this powder auger filler is the machine compositing electricity, light, instrument at an organic whole set, SCM control, which can automatically quantitative, fill and adjust the measurement error.
• High efficiency: adopting spiral feed in style, optical controlling technology.
• High precision: adopting step-motor and electronic weighing technology.
• Widely packaging range: same sets quantitative packaging machine in 5-5000g through electronic keyboard adjustment and replacement of different specification feed in spiral controller is continuously adjustable.
• Widely application: liquidity powder form, granular materials etc.
• This powder filling machine suitable for bags, cans, and various bottle container powder quantitative packaging.
• For errors of material proportion and material level caused by changes can be tracked and modified.
• Photoelectric switch controlling system, only artificially bagging, clean, easy sealing.
• Contacting materials parts of the Semi Auto powder packing machines are made of stainless steel, convenient cleaning, preventing cross pollution.
• Configurable stuff servicer, more user-friendly.

Working Process:

Manually bag placing → Automatic filling → Automatic weighing → Automatic conveying → Automatic sealing (sewing, heating or weld) → next process

Technical parameters:

• Model: DCS-Y5
• Weighing Range: 5g-5000g
• Packing Speed: 1500-2000 bags/hour
• Precision: ±1%FS
• Power: 900W
• Electrical Power: AC380/220,50/60(V/Hz), 3/1 phase, made as per requirement
• Weight: 280kg
• Dimension: 1000×850×1850mm
• Packaging container: Aluminum foil bag, plastic bag, bag, paper bag, bottle, etc
• Air Source Pressure: 0.4-0.6Mpa
