Three Side Sealing Granule Packing Machine

VIDEO

Introduction

This automatic granule packing machine adopts a PLC programmable controller as well as an English display screen that makes it easy to operate and convenient to be adjusted.
The use of advanced photoelectric digital tracking system makes it possible to set the length of package and when packing film with cursor mark is used, the first package is able to seize the cursor mark and get correct designed patterns. Synchronous package pulling system makes the movement of the packages smooth and accurate. Sealed, insulated and corrosion-proof soft touching display screen is provided.
This granule packaging machine can automatically complete a series of actions, such as bag making, the measuring, filling, inflating, counting, sealing, code printing, material giving, stopping in certain quantity, fixed-bag cutting and same cutting.

Application:

This automatic granule pouch packing machine is widely used to pack any loose, non-cohesive granule products of the food, pharmaceutical, and chemical industries, such as soup mix, coffee, instant drink mix, desiccant, MSG, sugar, salt, cereal, shrimp, peanuts, melon seeds, spices, beef bean, detergent and other granular materials.

Features:

1. Using microcomputer touch screen control and intelligent temperature control system, and photoelectric tracker.
2.  Automatic granule packaging machinery use intelligent photoelectric controller system. Accurate positioning and it is easy to adjust.
3.  Small noise, stable system and easy operation.
4.  Frequency stepless speed, and configure different cutting institutions to achieve the packing of particles, liquid, body butter, powder and other items.
5.  All the machine is using ss304 stainless steel, healthy, safety and easily cleanable.
6.  This granule filling machine is very easy for maintenance, all the adjustment can be done on color touch screen.
7.  High output, the continuous running makes it very high efficiency.

Specification:

Packing step:

1. elevator
2. Film roll
3. Vertical sealing
4. Counting cups dispensing
5. Horizontal sealing

Optional:

1. Conveyor
2. Weighing scale
3. Hoister
4. Printer
5. Screw dispensing device
