Four Side Sealing Granule Packing Machine

VIDEO

Introduction

This highly automatic granule packing machinery uses a PLC programmable controller and an English display screen. It is easy to operate and convenient to be adjusted according to detailed requirements.
Advanced photoelectric digital tracking system makes it possible to set the length of package and the first package will be able to seize the cursor mark and get correct designed patterns when packing film with cursor mark is used, Synchronous package pulling system makes the movement of the packages smooth and accurate.
Automatic granule package machine is widely used for packing any loose, non-cohesive granule products in food, pharmaceutical, and chemical industries like soup mix, coffee, instant drink mix, desiccant, monosodium glutamate, sugar, salt, cereal etc.

Features:

1. This sachet granule packing machine can automatically complete following work: cup volumetric filler measuring—coding (optional)—bag making--filling--gas injection/exhaust (optional)--sealing--counting.
2.  Computer/PLC control system, photoelectric tracking, high reliability and intellectualized degree.
3.  This granule filling machine has fault display system, easy to operate and maintenance.
4.  Punching blade (round/ euro hole) and linked bags device are available.
5.  Machine body and all food touching part are made by stainless steel (measuring cup material: nylon/stainless steel).

Specification

Packing step:

1. Fill products to the hopper
2. Film roll
3. Vertical seal
4. Counting cup dispensing
5. Horizontal seal

Optional:

1. Conveyor
2. Weighing scale
3. Hoister
4. Printer
5. Screw dispensing device
